10 Connector Panel

The HDR07 can be used with the following backplane: BPH07.

And fiber backplanes: BPH07T_FC/PC, BPH07T_SC,

BPH07R_SC and BPH07R_FC/PC

HD/SD SDI INPUT (OPTIONAL FIBER INPUT)

HD/SD SDI OUTPUT 1

HD/SD SDI OUTPUT 2

HD/SD SDI OUTPUT 3 (OPTIONAL FIBER OUTPUT)

HD/SD SDI OUTPUT 4

HD/SD SDI OUTPUT 5

HD/SD SDI OUTPUT 6

HD/SD SDI OUTPUT 7

BPH07

!Unused inputs and outputs must be terminated

with the correct impedance!
