TECHNICAL SPECIFICATIONS
Model MFPH32-1280
Cooling Capacity (Btu/h)/ W 12.000 Btu/h / 3500 W
Heating Capacity (Btu/h)/ W 12.000 Btu/h / 3500 W
Dehumidifying Capacity (l/h) 1.8 l/h
Standard Cooling Input Power/Current 1200 W/5,2 A
Heating Input Power/Current 1150 W/5,0 A
Air Flow Volume (m³/h) 400 m3/h
Rated Voltage /Frequenc(V/Hz) 220-240 V~/50 Hz
Sound Pressure Level (dB (A)) LPA ≤55 dB (A), LWA≤65 dB (A)
Rated Energy Eciency Ratio (EERrated) 2,6
Rated Coecient Of Performance (COPrated) 2,4
Global Warming Potential (kg CO ) 2100
EER /COP Class A / A
Net Weight (Kg) 29.5 kg
Dimensions W X D X H 400 x 387 x 794 mm
Refrigerant R410A
Applying Space (m²) 24 - 29 m2
Fuse 3,15 A / 250 V ø5 x L 20 mm
IP protection level IP X0
Dimension of the condensation water outlets 15 mm
TROUBLESHOOTING
The following cases may not always be a malfunction. Please check suggestions below before
asking for service.
Failures Analysis
Does not run • If the protector trip or fuse is blown.
• Please wait for 3 minutes and start again, protector device may be
preventing unit from working.
• If batteries in the remote controller are exhausted.
• If the plug is not plugged in properly.
Runs for a short
while only
• If the set temperature is close to room temperature, you can lower
the set temperature.
• Air outlet is blocked by obstacle. Take the obstacle away.
Runs but no cooling • If the door or window is open.
• If there is another appliance heat-working like heater or lamp etc.
• The air filter is dirty, please clean it.
• Air outlet or intake is blocked.
• Set temperature is too high.
Water leak during
moving
• Drain the condensate before moving.
• To avoid water leakage, please locate the unit on flat ground.
Does not run and
water full indicator
„E4“
• Pull out the rubber plug to drain water.
• If it is often in this state, please contact qualified service centre.
DISPOSAL
Appliances, accessories and packaging must be recycled in an environmentally respon-
sible manner. Electrical appliances which are not longer serviceable can be returned
to retailers for recycling. Do not include electrical appliances in domestic rubbish. As
required by EU Directive 2002/96/EC on Waste Electrical and Electronic Equipment as well as
legislation enacting this into national law, electrical equipment which is no longer serviceable
must be collected separately and recycled in an environmentally responsible manner.
