TECHNICAL DRAWING
EU declaration of conformity
1. Apparatus model/Product
Product: 5.5KW Low-power Generating Set
Model: PDS 5500
batch or serial number: 1801-2012
2. Name and address of the manufacturer or his authorised representative:
CH-Import & Distribution exklusiv durch
Jumbo-Markt AG
Industriestrasse 34
8305 Dietlikon
3. This declaration of conformity is issued under the sole responsibility of the manufacturer.
4. Object of the declaration
Low-power Generating Set
Model: PDS 5500
Rated Power: 5000W
Brand: AYCE
5. The object of the declaration described above is in conformity with the relevant Union
harmonisation legislation:
2006/42/EC "Machinery Directive"
2014/30/EU “Electro Magnetic Compatibility”
2000/14/EC amendment by 2005/88/EC "Noise Directive"
(EU)2016/1628 amendment by 2017/656 "Emission Directive"
6. References to the relevant harmonised standards used, including the date of the standard:
EN ISO 8528-13:2016
AfPS GS 2014:01 PAK
EN 55012:2007/+A1:2009
EN 61000-6-1:2007
EN ISO 3744:1995
7. Additional information:
Measured sound power level: 96dB
Guaranteed sound power level: 97dB
Conformity assessment procedure under Directive 2000/14 / EC: Annex
Person authorised to compile the technical file:
Lisa Chen - ARENA
Parc de Tréville, 2 allée des Mousquetaires 91078 Bondoufle cedex - France
Signed for and on behalf of:
Place : Dietlikon
date of issue 10/4/2018
Signee: CEO
Jerôme Gilg
Red
White
Brown
Black
carburetor
elscticmagnet
charge
coil
battery
starter assy
white
red
red
black
black
FS
IG blue
buzzer
starter SW control
G
ignition coil
assy
spark
plug
low oil
sensor
AC 12V
POWER
AC BREAKER
STARTER SW
OFF
ON
START
1
2
3
4
5
6
1
2
3
4
5
6E
DC reset
M6
M6
M6
M6
E
IG
ABT
B
ST
G
FS
OFF
ON
START
CONNECTION
SYMBOL
KEY
POSITION
3 phases socket
Generator
Ground
Yellow/green
112
111
|
GB
