Refer to your notes describing which source
components are connected to which numbered
input.
Use the right-hand knob to scroll to the desired
numbered input (“
OFF 1” through “OFF 6”).
When you have reached the desired input number,
use the left-hand knob to scroll through the list of
available names (shown at the left). Selecting “
OFF”
disables that input, while selecting any other name
from the list will activate (enable) that input.
Select a name describing the source connected to the
chosen input, and it will automatically be entered
into memory. The display will show the name has
been assigned to the chosen input.
Repeat the process of naming the remaining desired
inputs. When all of the desired inputs have been
named, press the left-hand button to exit the basic
setup mode. The front panel will briefly display
“
EX SU” to indicate that the unit is exiting the
set up mode. Then the unit will return to the
low-power consumption mode, indicated by the
green LED in the right-hand switch.
8
OFF X
INx X
PC X
CD X
PH X
DVD X
SCD X
SSP X
DIG X
TNR X
AUX X
D/A X
DAT X
CDR X
CBL X
TV X
VCR X
LD X
DX5 X
C5X X
QB9 X
CX7 X
DX7 X
D1X X
EX SU
