Numbers and
Specifications
Power Output 60 watts per channel continuous into 8 ohms
120 watts per channel continuous into 4 ohms
Maximum Input Level 4 V rms – unbalanced inputs
8 V rms – balanced inputs
Input Impedance 20 kΩ– unbalanced inputs
40 kΩ– balanced inputs (20 kΩper phase)
XLR Input Polarity Pin 1 = Ground
Pin 2 = Non-inverting (Positive)
Pin 3 = Inverting (Negative)
Gain 35 dB (maximum, at volume level of “66”)
Frequency Response 2 Hz - 200 kHz
Power Consumption 20 watts in standby mode
70 watts in operating mode, no signal
Dimensions 17-¼" W x 13-¾" D x 4-¾" H
44 cm x 35 cm x 12 cm
Weight 25 pounds
11.5 kg
12
