AYRSTONE AyrMesh Setup Manual

Ensure:
• Router is powered on, and lights are on.
• Make sure Power Supply is connected to
Router with a separate Ethernet cable
(pic.2 & 3)
,
not the short cable attached to the Power
Supply.
(pic.1)
• Cables are clicked in on both ends.
• Computer is plugged into a LAN port,
not the WAN port. (LAN light should be lit)
• Computer gets IP address automatically.
Follow steps on right.
If the above steps did not resolve your issue Go To Step 5.
Windows: 7 and Vista
Open your Control Panel.
Select Networking or Network and Sharing Center.
Select Change Adapter Setting.
Right-Click Local Area Connection.
Select Properties.
Select TCP/IP or Internet Protocol Version 4
Select Properties
Ensure Obtain an IP address automatically is
checked.
Ensure comptuer is configured properly:
Mac:
Open System Preferences.
Select Network.
Select Ethernet.
Ensure Using DHCP is selected.
Email: support@ayrstone.com
Phone: 1-888-837-0637 x101
3
4 5
Troubleshoot
Login Page did not show on
screen
Troubleshoot
Unable to Connect to
Internet
scan with mobile device
www.Ayrstone.com/support
Contact Us
Additional Help
Visit Ayrstone.com/support
for detailed instructions, videos, slide shows,
and a troubleshooting guide.
Ensure:
• Internet access device is powered on.
• Internet access device is connected to the WAN
port.
• Reboot the Internet access device.
• Reconfigure Router connection settings.
• Connecting to an “all-in-one” router/gateway
device?
Put AyrMesh into the DMZ of the device:
Visit http://ayrstone.com/support for examples.
Contact your ISP for detailed instructions.
If the above steps did not resolve your issue Go To Step 5.
3
continued
(pic.2) (pic.3)
(pic.1)
