2
Assemble the Hub and
connect to router
A. Screw the antennae
gently onto the threads
on the Hub - nger-tight
(no tools):
B. Plug an Ethernet cable into either port on
the Hub - slide in until it clicks in place:
C. Click the other end of the Ethernet cable
into the port on the power supply marked
"POE":
D. Use another Ethernet cable to connect
the LAN port of the power supply to one of
the LAN ports on your router.
E. Plug the power
supply into the wall:
This is how the
setup should look:
F. The Power
light should
be on and the
top signal
light should
also start
blinking:
DO NOT FORCE
CONNECTORS IN OR
OUT OF PORTS!
