Azbil MCF0080 User Manual

■ Model selection guide
■ Optional parts (sold separately)
Basic Pipe size Material Connected Gas type Power Option Option Option Design Description
model Flow rate /output/ (1) (2) (3) code
number range communications
MCF MCF Air flowmeter
0080 8A (1/4B), 200L/min, full scale
0150 15A (1/2B), 500L/min, full scale
0151 15A (1/2B), 1000L/min, full scale
0250 25A (1B), 3000L/min, full scale
0400
40A (1 1/2B), 3000L/min, full scale
0500 50A (2B), 12000L/min, full scale
A Body: aluminum alloy
Rubber: HNBR
F Body: aluminum alloy
(Degreasing treatment *1)
Rubber: FKM
R Rc thread
GG thread
N Air/nitrogen
D01 24 Vdc power, 4 to 20 mA
output, one event output
D10 24 Vdc power, RS-485
0 None
0 None
. 0 None
D Inspection certificated provided
Y With traceability certification
0 Product version
Name Model number Description
Mounting bracket 81446721-001 For MCF0080/0150/0151/0250
Measurement module 81447192-201 For MCF____A_ND01____ For MCF0250/0400/0500
81447192-221 For MCF____A_ND10____
81447192-401 For MCF____F_ND01____
81447192-421 For MCF____F_ND10____
2
Chapter 1. OVERVIEW
Name Model number Cable Cable Lead color
length properties
Cable with connector PA5-4ISX2MK-E 2m Oil resistant, bend-tolerant
exclusive for MCF PA5-4ISX3MK-E 3m Flame-resistant cable
series PA5-4ISX5MK-E 5m UL2464 1: Brown
EN-compliant
2: White
PA5-4ISX2HK-E 2m Oil resistant
3: Blue
PA5-4ISX3HK-E 3m Flame-resistant cable 4: Black
PA5-4ISX5HK-E 5m UL2464
EN-compliant
Extension cable with PA5-4ISB2MK-E 2m Oil resistant, bend-tolerant
connector PA5-4ISB3MK-E 3m Flame-resistant cable
PA5-4ISB5MK-E 5m UL2464
EN-compliant
PA5-4ISB2HK-E 2m Oil resistant,
PA5-4ISB3HK-E 3m Flame-resistant cable
PA5-4ISB5HK-E 5m UL2464
EN-compliant
*1. page 38
