Azbil MCF0080 User Manual

● Wiring example
• 4 to 20 mA output models (MCF_______D01____)
• RS-485 communications models (MCF_______D10____)
Connect terminating resistors of 150 Ω±5%, 1/2 W min. at each end of the transmission line.
The FG grounding must not be made at the both shielded wire ends but only at one location.
Azbil Corporation’s CMC10L001A000 can be used as a converter of the host station.
Terminating resistor
Shield
Master station
MCF(Slave station)
DA
DB
SG
DA
DB
COM
FG
FG
V+
DA
DB
SG
FG
Slave station
4
2
3
1
Terminating
resistor
External connection exampleInternal circuit
Shield
22.8 to
25.2 Vdc
1
2
3
4
V
I
COM
EV
Instantaneous flow
rate output
4 to 20mA
Allowable load
resistance
(up to 300 )
Load
22.8 to 25.2 Vdc
30 Vdc or less
30 Vdc, 50 mA or less
External connection exampleInternal circuit
14
Chapter 3. MOUNTING AND WIRING
