AB-7258
4
Part Numbers of Optional Items
Mount Neostat with the following optional items (sold separately). Order necessary items.
Item Part number/Model number Note
Adapter Part No. 83172617-001 —
Auxiliary device Thermoplate for individual room
control
Model QY1100A With slide switch
Model QY1100C
With rotary switch
Model QY1100D
Thermoplate Part No. DY2000A1022 For mounting one Neostat, lengthwise
Part No. DY2000A1023 For mounting one Neostat, crosswise
Part No. DY2000A2023 For mounting two Neostat in
94mm (H) x 192mm (W) outlet box, crosswise
Part No. DY2000A2024 For mounting two Neostat in
106mm (H) x 198mm (W) outlet box, crosswise
Part No. DY2000A3022 For mounting three Neostat, crosswise
Thermoplate for open wiring
* Thermoplate for open wiring
is used for open wiring
installation.
Part No. DY2000A1021 For mounting one Neostat, square
Part No. DY2000A2021 For mounting two Neostat, crosswise
Part No. DY2000A3021 For mounting three Neostat, crosswise
Multi-Thermocase Model TY1100Z —
Protection cover 83104506-020 10 pcs
Specifications
Item Specification
Differential Model TY600_Z
Model TTY6023Z
1.5 ± 1 °C (in 10–30 °C range)
Model HY6000Z 5 ± 3 % RH (in 30–90 % RH range)
Temperature difference
between steps
(of two-position, two-step
control)
Model TTY6023Z 2 ± 1 °C fixed (in 10–30 °C range)
Proportional band Model TY900_Z 2 ± 1 °C fixed (in 10–30 °C range)
Sensing elements Thermostat Temperature-sensitive diaphragm
Humidistat Moisture-sensitive nylon ribbon
Environment conditions Rated operating conditions Transport/storage conditions
Model TY600_Z
Model TTY6023Z
Model TY900_Z
Ambient temperature 0–50 °C -20–50 °C
Ambient humidity 10–90 % RH
(without condensation)
5–95 % RH
(without condensation)
Model HY6000Z Ambient temperature 10–40 °C -20–50 °C
Ambient humidity 10–90 % RH
(without condensation)
5–95 % RH
(without condensation)
Contact rating of two-position control*
*
125 V AC 250 V AC 24 V DC
Model TY600_Z Operating 6 A 3 A 1 A
Startup 36 A 18 A 10 A
Resistive load 6 A 3 A 2A
Model TTY6023Z Operating 4 A 2 A —
Startup 18 A 9 A —
Resistive load 4 A 2 A —
Contact rating of two-position control*
*
*
125 V AC 250 V AC 24 V DC
Model HY6000Z Operating 4.4 A 2.2 A 0.4 A
Startup 26.4 A 13.2 A 2 A
Resistive load 8 A 4 A 1 A
Color Pale gray (BN-85, Japan Paint Manufacturers Association in 2003)
Materials
Cover PC resin
Base PC resin
Weight Approx. 180 g
Installation With the mounting kit (sold separately)
Connection
Model TY600_Z
Model TY900_Z
Model HY6000Z
Connections using the terminal blocks
Model TTY6023Z Lead wire connection
Accessory Two mounting screws (M4 x 10 mm, pan-head screw)
Notes:
*1 Minimum allowable current is 50 mA.
*2 Contact rating of the humidistat model (Model HY6000Z) shown above is the maximum current at startup and in operation when Model
HY6000Z is connected to dehumidifier/humidifier.
*3 Select a device (load) of which the Neostat contact rating is tolerable. If a load larger than the Neostat contact rating is connected to Neostat,
the contact may be welded and may not turn on or off.
