1ª 10155 ES 9 - 2009
25
G4 Validator: manages the coins inserted by accepting them or rejecting them. It measures,
among other parameters, the sound produced by the coin on entry. It is capable of recognising
legal coins and rejecting all known frauds.
For more technical information see the technical manual of the Validator
G5 Coin sorter: directs the coins accepted by the validator to the Hopper, to the "V" escrow or to
the refund collection tray.
For more technical information see the technical manual of the Sorter
G6 Hopper: is used to supply the change needed after a purchase of a product if necessary. It
is auto refilled with the coins introduced by the users. It can work with all the coins and can be
configured the by simply changing the programming.
The capacities of coins are indicated in the following table:
Coin €
Coins
-capacity-
0,05 775
0,10 775
0,20 600
0,50 375
1 425
Hopper U
2 325
The Hopper U is managed by the machine using the protocol of
communication called CCtalk
The machine recognises each one of the three Hopper U-II using “addresses” that are
configured with two dip-switches located on the control board and that can be
accessed on the underside of the Hopper U.
