Azkoyen STEP 41 - Updating Control Board from Flash Board

1ª 10155 ES 9 - 2009
36
Procedure for updating:
1
st
Ensure that the machine or Rack is switched off.
2
nd
Connect the PC with the communication cable ref. 43210820-2. Loom RS232 to the
control board in the connector UART1.
3
rd
Start the programme LOADER installed in the PC.
4
th
Select the file with extension .S19 that is to be used.
5
th
Switch on the machine.
The updating of the programme will start automatically.
The time for the update is approx. of 1 minute
15.5.3 Updating of the control board of the machine from a flash board
You need the Flash board with the programme loaded and installed in the Control board of the
machine.
Procedure for updating:
1
st
Ensure that the machine or Rack is switched off.
2
nd
Take the RAM memory board out of Control board and put in the Flash board.
3
rd
Switch on the machine.
The updating of the programme will start automatically.
The memory flash will be updated when you hear 3 beeps
The time for the update is approx. of 20 seconds
