MESSAGE FAULT VALIDATOR
Definition Fault validator.
Observations A fault is detected by the control board of the machine.
PROBABLE CAUSE
x The exit signal of a coin is activated.
FAULTY PART
- Coin validator. The control board interprets
that it is receiving a coin code.
- Control board of the machine.
MESSAGE FAULT REFUND
Definition Fault in the motor of refund.
Observations This fault is detected by the control board of the machine.
PROBABLE CAUSE
x After a refund, the microswitch stays
activated.
x The motor tries a circuit but cannot
deactivate the microswitch.
FAULTY PART
- Refund motor.
- Wiring of the motor.
- Microswitch.
- Wiring microswitch.
- Control board Hopper assembly.
- Loom Hopper assembly.
- I/O Board.
- Control board.
x The motor tries a circuit but cannot
deactivate the microswitch
.
- Control board Hopper assembly
- I/O Board
- Control board.
MESSAGE WITHOUT PRG. PRICES
Definition No prices are programmed.
Observations This fault is detected by the control board of the machine.
PROBABLE CAUSE
x The prices of the different selections have
not been programmed using the functions of
programming the prices.
FAULTY PART
- Programming of the prices incorrect.
- Memory RAM of the control board faulty.
