MESSAGE FAULT CHANNEL X
Definition Fault in the channel indicated ( X = 11... ...N ).
Observations This fault is detected by the control board of the machine.
PROBABLE CAUSE
x The motor extractor «X» has not finished
the extraction cycle.
FAULTY PART
- Jammed product.
- Motor extractor.
- Microswitch.
- Board of extraction.
- I/O Board.
- Control board.
- Loom extraction.
x The empty channel detector is activated. - Jammed product.
- Motor extractor.
- Microswitch.
MESSAGE EMPTY TUBE. X
Definition Empty hopper indicated (X = A, B or C).
Observations This fault is detected by the control board of the machine.
PROBABLE CAUSE
x The level of coins is below minimum of the
hopper indicated.
x The level of coins is below the minimum
programmed.
FAULTY PART
- None.
x The coins are not detected by the minimum
control.
- Microswitch (of minimum level).
- Loom hopper.
- Control board Hopper assembly
- Loom Hopper.
- I/O Board.
- Control board.
- Control Board Hopper.
