If Reset Button is pressed for 3 seconds, this LED will
turn OFF and turn ON.
Device is not connected to a HomePlug AV2 network.
When Simple Connect is pressed for 10 seconds,
this LED will turn OFF to confirm the Private
Network Name reset.
This LED is steady in color when the device is part
of a HomePlug AV2 network.
The LED colors represents the connection rate
within the HomePlug AV2 network whether it is
good (red), better (amber), or best (green).
Ethernet
Activity
LEDs
1 & 2
An Ethernet device is connected to the corresponding
port.
The corresponding LED is steady when an
Ethernet device is connected.
When Simple Connect is pressed for 10 seconds,
this LED will turn OFF and turn ON to confirm the
Private Network Name reset. (Ethernet is
connected)
The LED flashes to indicate Ethernet activity.
