User Manual
Page 7 of 40
Device Design
HomePlug AV2 is on a Power Saving Status if the
Power LED is blinking slowly.
When Simple Connect is pressed for 10 seconds,
this LED will turn OFF and turn ON to confirm the
Private Network Name reset.
After Simple Connect is pressed for 2 seconds, this
LED will blink to confirm the button press.
Accepts either cross or straight Ethernet cable.
Press for 3 seconds then release button to reset to the factory
default settings. When you reset to the factory default, all your
configuration changes will be removed.
When Simple Connect is pressed for 10 seconds, it will
randomize the Private Network Name.
Press 2 seconds to join or add to another network.
