Operating instructions
Use and maintenance manual
PROBLEM SOLUTION
1
THE WARNING LIGHTS IN THE
CONTROL BOARD DO NOT
LIGHT UP
1 CHECK POWER SUPPLY ( 230 V )
1 CHECK FUSE
2
THE DOOR DOES NOT MOVE
WITH P1 AND P2 BUTTON
2 CHECK SETTING MOTOR WITH PROGRAMMER
(SETTING PARAMETERS – MOTOR TYPE ……KW)
2 RELEASE STOP BUTTON (LED 6 turned on)
2 CHECK MOTOR CONNECTION (triangle 230V three-
phase, star 380 three-phase)
3
YOU CAN NOT COMPLETE THE
SETTING OF THE CARD
3 CHECK WITH PROGRAMMER PARAMETER
OPTION IN USE 4300 FOR SINGLE PHOTOCELL
4380 FOR DOUBLE PHOTOCELL
(with encoder)
3 RELEASE THE STOP BUTTON (LED 6 turned ON)
3 MOVE THE DOOR WITH BUTTON P1 AND P2 OF
40/ 50 CM AND LOCATE IT ON CLOSE POSITION (
this operation is useful to recognize the encoder )
3 VERIFY THAT THE LED LD13 (radio safety edge or
sensor in the upper case) IS ON
3 IF NOT, MAKE JUMPERS 7 /13 AND CONTROL
THEN THE SECURITY COMPONENTS
3 INVERT THE ENCODER CABLE (yellow with green )
3 FOR DOORS WITH UPPER PHOTOCELL CONTROL
THAT LD 3 IS OFF WHEN THE DOOR IS CLOSE
4
YOU CAN NOT COMPLETE THE
SETTING OF THE CARD
4 CONTROL THAT THE LIMIT SWITCH ARE
CORRECTLY REGUALATED ( if FCC and FCRC
aren’t pressed the card can’t be set)
(with limit switch )
4 VERIFY THAT THE LED LD13 (radio safety edge or
sensor in the upper case) IS ON
4 VERIFY THAT THE LED LD7 (safety photocell ) IS
