B.M.P. DYNAMICROLL - OPERATION MODES; CONTROL CARD OPERATION MODES; MANUAL OPERATION

Operating instructions
Use and maintenance manual
ThisisaverticaloperationhighspeeddoorwithPVCcurtain.
Withthedoorareprovided:
Openingsystem(N.O.):
− Greenbuttononcontrolboardandagreenbuttonintheoppositesidetothecontrolboard,when
pressedtheyopenthedoor.
Securitysystem(N.C.):
− Emergencyred
buttononthecontrolboarditstopimmediatelythedoorifpressed.
− Photocellto40/50cmfromthefloor,itstopandreversethe doorinclosingifinterrupted.
− Asafetysensornearrollertube,itcontrolscurtainwrappinganditstopthecurtainifduringthe
closurecurtain
supportonanobstacle.
CONTROL CARD OPERATION MODE
- AUTOMATIC CLOSING ADJUSTABLE (*)
ThissystemallowtoopenthedoorwithSTARTcommandandadju stmentofpausetimeforautomaticclosing.

Toenablethismodeofoperationpositionthe dipswitch1onON
(*)Factorymodeoperation
- STEP BY STEP
ThissystemallowtoopenthedoorpressingSTARTbutton.
Thedoor
closesafterpressingagainSTARTbutton.

Toenablethismodeofoperationpositiondipswitch1onOFF
WARNING!!! THIS LOGIC DO NOT EXECUTE THE AUTOMATIC CLOSING
MANUAL OPERATION
OPERATION
