Test Procedure
© b2 electronic GmbHDHV0086 Rev0664
Step Procedure (Congureautomaticsequence)
AS07: Voltage not reached
Set action to be taken in case voltage is
not reached:
• No Action (default)
• Fail: Runs to end
• Fail. Immed. Stop
AS08: Min� Insulation Resistance
Set action to be taken in case minimum
insulation resistance is reached:
• No Action (default)
• Fail: Runs to end
• Fail. Immed. Stop
AS09: Test Parameters – Use period count
Set period count:
• time (see AS11)
• period (see AS16)
