HOW TO INSTALL THE CAR SEAT
1. Pull the ISOFIX Pulling Han-
dle ISOFIX will stretch to max.
length. Make sure ISOFIX is
on”open” status.
3. Pull the ISOFIX Adjusting
Handle outward and push the
car seat to make sure the it is
touching the Backrest of the
Vehicle seat .
2. Click the ISOFIX connectors to
the ISOFIX anchorage points
in the vehicle seat.Make sure
that All lSOFIX indicators are
GREEN
4. Place the belt half a round
from front and unlock it to
the buckle holder,then you
will hear “click”, Slide the belt
Into shoulder belt guide and
under the base handle
Notice: Make sure the back of the seat is touching the backrest of the vehicle seat.
If the headrest of the vehicle is pushing the seat away from the backrest adjust
the headrest;
Notice: if the seat can not be used in combination with ISOFIX anchorage points
in the vehicle seat the ISOFIX connectors can be stowed inside the seat and the
seat can be used in combination with the 3 point belt.
