Fixation and wrapping of float ball
Operating height is the water level above sump bottom during operation.
Operating water level
1. Operating height
2. Overflow
Operating heights for the evaporative cooling equipment are indicated in the tables below:
Model Operating height (measured from pan bottom)
(mm)
VXC-14 through 135 340
VXC-150 through 205 420
VXC-221 through 265 430
VXC-S288 through S1010 430
VXC-C220 through C426 460
VXC-357 through 454 460
VXC-562 through 714 460
VXC-798, 908, 1124 through 1360 460
VXC-495, 516, 715, 772 350
VXC-804, 990, 1032 350
VXC-1430 through 1608 350
W W W . B A L T I M O R E A I R C O I L . E U
18
