3015-9005 Rev 1 5
Spec Description
Sensitivity
[3]
0.006 oz/yr stationary
0.1 oz/yr moving per
SAE J2791
Auto adjust to
background
Yes, automatic mode only
Warm-up 2 min (typical)
Indication
Visual Red LED in probe tip
Audible
Internal beeper or stereo
headphone jack
Weight 5.1 lb. (2.3 kg)
Dimensions
(LxWxH)
10.5 x 8.3 x 5.4 in.
(267 x 211 x 137 mm)
Operating
Conditions
32 to 104 °F
(0 to 40° C)
Approvals CE
Warranty
3 years
[1]
Based on normal use. Consistent and/or
constant exposure to high levels of refrigerant
will deteriorate the sensor life more quickly.
Increasing the sensor heater will also impact
sensor life.
[2]
DO NOT use this device to detect for leaks of
refrigerants which are rated as combustible/
flammable gases (e.g., ASHRAE A2- or A3-rated
refrigerants).
[3]
Sensitivity for R12, R22, R134a, R410a, R404a and
R507 when unit is set to small leak setting,
manual mode.
∇ ∇ ∇
