What to do if the red light is on and the green LED is off on Bacharach Security Sensors?
If the red light is on and the green LED is off on your Bacharach Security Sensors, indicating a fault, first check that the sensor is properly inserted into the board. If the issue persists, the sensor might be damaged or has reached the end of its life. Contact Bacharach for further instructions and support.
How to troubleshoot Bacharach Security Sensors when both green and red lights are off?
If the green and red lights are off on your Bacharach Security Sensors, check the power supply and wiring. It is also possible that the MGS-150 was damaged during transit. To confirm this, try installing another MGS-150 to see if the fault persists.
Legal notice regarding copyright protection and reproduction of the manual.
Important safety and operational notes for qualified technicians installing and using the unit.
Describes the MGS-150's purpose, applications, and capabilities.
Details power supply, LEDs, outputs, IP rating, temperature, dimensions, and approvals.
Guidance on where to install the MGS-150 sensor for maximum sensitivity and minimal false alarms.
Explains wiring conventions and internal components of the sensor.
Introduces the configurable functions like time delay, audible alarm, and outputs.
Details how to set the trip point for the relay and audible alarm.
Explains the requirement for annual testing and calibration due to regulations.
General| Type | Gas Detector |
|---|---|
| Detection Method | Electrochemical |
| Power Supply | 24 VDC |
| Enclosure Rating | IP66 |
| Output | 4-20 mA |
| Operating Temperature | -40 to 50 °C |
| Humidity Range | 15-90% RH non-condensing |
| Certifications | ATEX, CSA, UL |
