Parts Identification
Wood Components
(NOT TO SCALE)
SB74 - SWING BEAM EXTENDED - W102419
2"x5 1/4"x89 1/2" (50x134x2274)
(1)
SP1 - FLOOR SUPPORT CLEAT - W100711
1"x1"x53 3/8" (24x24x1356)
(2)
W71 - SWING BEAM SUPPORT - W102420
2"x3 3/8"x49 5/8" (50x86x1260)
(1)
(3) FP1 - FLOOR PANEL - W102861
M16 - TARP SUPPORT - W101237
5/8"x3 3/8"x29 1/8" (16x86x740)
(2)
M18 - PICKET - W103761
5/8"x3 3/8"x18 7/8" (16x86x480)
(4)
M71 - ROCK BOARD - W100022
5/8"x3 3/8"x20 1/4" (16x86x514)
(6)
M72 - ROCK WALL SLAT - W100023
5/8"x3 3/8"x20 1/4" (16x86x514)
(2)
M77 - SLIDE BRACE - W100544
5/8"x3 3/8"x17 1/4" (16x86x438)
(1)
M78 - CENTER SLIDE BRACE - W100545
5/8"x3 3/8"x17 1/4" (16x86x438)
(2)
M17 - PICKET - W100705
5/8"x3 3/8"x27 1/8" (16x86x690)
(4)
