Backyard Discovery 55006 - Bench Attachment to Structure

BOLT WH
5/16x1/2
(2)
WASHER
LOCK EXT
12x19
(2)
NUT BARREL
WH 5/16x5/8
(2)
STEP 26
USING BENCH ASSEMBLY BRACKETS AS A TEMPLATE, DRILL TWO 3/8" THRU HOLES
AND ATTACH EJ BRACKET TO L2 GROUND BOARD USING (2) 1/2" BOLTS, LOCK
WASHERS AND 5/8" BARREL NUTS, AS SHOWN.
(1) - BENCH ASSEMBLY
7-1/2" BENCH LOCATION
NUT BARREL WH 5/16x5/8
(2 PLCS)
WASHER LOCK EXT 12x19
(2 PLCS)
BOLT WH 5/16x1/2
(2 PLCS)
