Backyard Discovery 55006 - Attaching Ground Boards to Frame

E2
L2
E2
L2
E3
E1
NUT BARREL WH 5/16x7/8
(8 PLCS)
WASHER LOCK EXT 12x19
(8 PLCS)
WASHER LOCK EXT 8x19
(8 PLCS)
STEP 3
ATTACH THE L2 BOARDS TO THE E1, E3 AND E2 BOARDS USING
HARDWARE AS SHOWN THROUGH PRE DRILLED HOLES.
L2 - GROUND BOARD - W100684
5/8"x4 3/8"x60 1/8" (16x112x1528)
(2)
NUT BARREL
WH 5/16x7/8
(8)
WASHER
LOCK EXT
12x19
(8)
WASHER
LOCK EXT
8x19
(8)
BOLT WH
5/16x1 1/2
(8)
BOLT WH 5/16x1 1/2
(8 PLCS)
