Backyard Discovery 55006 - Attaching Lower Face and Ground Boards

STEP 2
ATTACH THE M6 BOARDS AND THE L5 BOARD TO THE E3 AND E1 BOARDS
USING HARDWARE AS SHOWN THROUGH PRE DRILLED HOLES.
NOTE THE ORIENTATION OF THE E3 AND E1 BOARDS.
E3 - UPRIGHT - W101256
1 3/8"x3 3/8"x81 3/4" (36x86x2076)
(1)
E1 - UPRIGHT - W101261
1 3/8"x3 3/8"x81 3/4" (36x86x2076)
(1)
M6 - LOWER FACE BOARD - W101598
5/8"x3 3/8"x38 5/8" (16x86x982)
(2)
L5 - GROUND BOARD - W100686
5/8"x4 3/8"x30" (16x112x762)
(1)
SCREW PFH
8x1 1/2
(10)
WASHER
LOCK EXT
8x19
(4)
E1
E3
M6 M6
L5
LAG SCREW WH 5/16x2
(4 PLCS)
WASHER LOCK EXT 8x19
(4 PLCS)
SCREW PFH 8x1 1/2
(10 PLCS)
LAG SCREW
WH 5/16x2
(4)
