Backyard Discovery 55006 - Main Fort Structure Assembly; Attaching Face Boards to Uprights

M5 - FACE BOARD - W101599
5/8"x3 3/8"x43 1/8" (16x86x1094)
(2)
SCREW PFH
8x1 1/2
(6)
SCREW PFH 8x1 1/2
(6 PLCS)
NOTE THE HOLES THAT ARE USED
STEP 1
ATTACH M5 BOARDS TO E2 BOARDS USING HARDWARE AS SHOWN
THROUGH PRE DRILLED HOLES.
NOTE THE ORIENTATION OF THE HOLES WITH THE E2 BOARDS.
E2
E2
M5
M5
E2 - UPRIGHT - W103773
1 3/8"x3 3/8"x81 3/4" (36x86x2076)
(2)
