Backyard Discovery 55006 - Bench Assembly; Bench Component Assembly

STEP 25
ATTACH (2) EJ BRACKETS TO H6
BENCH GROUND BOARDS USING
(2) 1/2" BOLT, LOCK WASHERS
AND 7/8" BARREL NUT, AS
SHOWN.
ATTACH H5 BENCH UPRIGHTS TO H6 BENCH GROUND
BOARDS USING (8) 1-3/4" WOOD SCREWS, AS SHOWN.
ATTACH H4 BENCH SEAT SUPPORTS TO H5 BENCH
UPRIGHTS USING (8) 1-3/4" WOOD SCREWS, AS SHOWN.
ATTACH M2 BENCH SEATS TO H4 BENCH
SEAT SUPPORTS USING (8) 1-3/4" WOOD
SCREWS, AS SHOWN.
EJ - L BRACKET 54x67 - A100053
(2)
BOLT WH
5/16x1/2
(2)
SCREW PFH
8x1 3/4
(24)
WASHER
LOCK EXT
12x19
(2)
NUT BARREL
WH 5/16x7/8
(2)
M2 - BENCH SEAT - W104044
5/8"x3 3/8"x27 3/8" (16x86x694)
(2)
H5 - BENCH UPRIGHT - W104041
1"x3 3/8"x11 3/4" (24x86x300)
(2)
H4 - BENCH SEAT SUPPORT - W104040
1"x3 3/8"x6 1/2" (24x86x166)
(2)
H6 - BENCH GROUND BOARD - W104042
1"x3 3/8"x18 1/8" (24x86x460)
(2)
SCREW PFH 8x1 3/4
(8 PLCS)
BOLT WH 5/16x1/2
(2 PLCS)
WASHER LOCK EXT 12x19
(2 PLCS)
NUT BARREL WH 5/16x7/8
(2 PLCS)
SCREW PFH 8x1 3/4
(8 PLCS)
SCREW PFH 8x1 3/4
(8 PLCS)
