Backyard Discovery 55006 - Monkey Bar Assembly; Building Monkey Bar Rails

MONKEY BAR ASSEMBLY
STEP 1
YOU WILL BUILD A LEFT AND RIGHT TOP RAIL IN THIS STEP.
AFTER BUILDING LEFT ASSEMBLY AS SHOWN, REPEAT STEPS
FOR A RIGHT ASSEMBLY. SEE BELOW FOR OREINTATION OF
RIGHT SIDE TRIANGLE PLATE.
ASSEMBLE WITH HARDWARE AS SHOWN.
BE SURE TO PLACE FLAT SIDE OF PLATE
AGAINST SIDE OF BOARD.
RIGHT SIDE VIEW OF TRINANGLE PLATE
EJ
QZ
E71
QZ - TRIANGLE PLATE 100 5 HOLE - A100294
(2)
EJ - L BRACKET 54x67 - A100053
(2)
E71 - MONKEY BAR RAIL - W102369
1 3/8"x3 3/8"x60 5/8" (36x86x1539)
(2)
QZ
E71
BOLT WH
5/16x1-1/2
(6)
BOLT WH
5/16x1
(2)
T-NUT 5/16
(6)
NUT BARREL
WH 5/16x7/8
(2)
WASHER
LOCK EXT
12x19
(2)
