Backyard Discovery 55006 - Page 30

H81 - MONKEY BAR BRACE - W100993
1"x3 3/8"x53 1/4" (24x86x1352)
(2)
H82 - MONKEY BAR GROUND BOARD - W100994
1"x3 3/8"x70 3/8" (24x86x1786)
(1)
STEP 4
ASSEMBLE AS SHOWN.
MONKEY BAR ASSEMBLY
H81
H81
H82
BOLT HEX
5/16x2-3/4
(2)
WASHER
LOCK INT
8x15
(2)
WASHER
FLAT 9x18
(2)
BOLT WH
5/16x1-1/2
(4)
LAG SCREW
WH 5/16x2
(4)
WASHER
LOCK EXT
8x19
(8)
WASHER
LOCK EXT
12x19
(4)
NUT BARREL
WH 5/16x7/8
(4)
T-NUT 5/16
(2)
