Backyard Discovery 55006 - Page 59

BOLT HEX
5/16x1
(4)
SCREW PWH
8x5/8
(4)
WASHER
SPLIT 5/16
(4)
WASHER
FLAT 8x27
(4)
HC - BYD ID TAG (LARGE) 2011 WITH AGES - A100164
(1)
(1) - SWING BEAM ASSEMBLY
STEP 29
ATTACH SWING BEAM ASSEMBLY TO K1 ROOF SWING BEAM SUPPORT USING (4) 1"
BOLTS, SPLIT WASHERS AND FLAT WASHERS, AS SHOWN BELOW.
ATTACH HC I.D. TAG TO SB74 SWING BEAM USING (4) 5/8" PFH SCREWS, AS SHOWN.
BOLT HEX 5/16x1
(4 PLCS)
WASHER SPLIT 5/16
(4 PLCS)
WASHER FLAT 8x27
(4 PLCS)
SCREW PWH 8x5/8
(4 PLCS)
