192
(x2)
199
(x2)
198
(x2)
378
(x2)
Hardware Identi cation
Hardware bags are printed with
a seven digit alpha-numeric part
number. During assembly you only
need to reference the last three
digits of the part number as noted
in each step. This will make nding
the correct hardware easier.
BOLT WH
5/16 x
1-3/4
ASSEMBLY TIP:
Keep and eye out for these boxes which will c
ontain helpful pictures and information making
the assembly process as quick and painless as possible.
Sorting Wood
Sorting Hardware
W
hen removing the wood from the boxes we recommend arranging them by part number before you begin
assembly. This will allow for faster assembly and easily identify any parts that may be missing or damaged.
To help with assembly we recommend sorting your hardware bags with the seven digit alpha-numeric number
printed on the bags or by hardware type (i.e. bolts, nuts, etc.). Organizing your hardware will make assembly easier.
NUT BARREL
H100545
SCREW
H
100695
T-NUT
H100699
WASHER FLAT
H100706
BOLT HEX
H100716
BOLT
H100718
SCREW PWH
H100742
H100378
(x2)
Assembly Tips
Owner’
s Manual
