Wood Components (Not to Scale)
Parts Identification
LEFT FRONT UPRIGHT - W4L14880
1 3/8"x3 3/8"x62 3/8" (36x86x1584)
E1
(x1)
RIGHT FRONT UPRIGHT - W4L14881
1 3/8"x3 3/8"x62 3/8" (36x86x1584)
E2
(x1)
RIGHT REAR UPRIGHT - W4L14882
1 3/8"x3 3/8"x62 3/8" (36x86x1584)
E3
(x1)
LEFT REAR UPRIGHT - W4L14883
1 3/8"x3 3/8"x35" (36x86x889)
E4
(x1)
FLOOR RAIL - W4L14889
1"x3 3/8"x54 7/8" (24x86x1394)
H2
(x1)
COUNTER TOP SUPPORT - W4L14919
1"x3 3/8"x8 3/8" (24x86x214)
H3
(x1)
FLOOR RAIL - W4L14891
1"x3 3/8"x54 7/8" (24x86x1394)
H4
(x1)
FLOOR RAIL - W4L14888
1"x3 3/8"x56 3/4" (24x86x1442)
H1
(x2)
FLOOR SUPPORT - W4L14892
1"x3 3/8"x54 7/8" (24x86x1394)
H5
(x2)
GROUND BOARD - W4L14884
1"x5 1/4"x56 3/4" (24x134x1442)
G1
(x2)
GROUND BOARD - W4L14885
1"x5 1/4"x54 7/8" (24x134x1394)
G2
(x2)
WALL RAIL - W4L14893
1"x3 3/8"x18 1/2" (24x86x469)
H6
(x2)
WALL RAIL - W4L14894
1"x3 3/8"x56 3/4" (24x86x1442)
H7
(x1)
WALL RAIL - W4L14895
1"x3 3/8"x34 1/4" (24x86x871)
H8
(x1)
