Safe Play Zone
General Information:
Your set has been designed and engineered for children only and for residential use only.
A maximum of 150 lbs. per child is recommended for play activities designed for individual use.
A maximum of 120 lbs. per child is recommended for play activities designed for multiple child use.
A maximum of 6 children is recommended for this playhouse.
Ground Dimension
6.25 ft [1.9 m] x 10.02 ft [3.1 m]
Safe Play Area
19.42 ft [5.9 m] x 23.19 ft [7.1 m] x 14.18 ft [4.3 m]
SAFE PLAY AREA DIAGRAM
Selecting the correct location for your play product is important for your children’s
safety and the product’s longevity
• The safe play area refers to a zone extending 6'-7" (2m) beyond the play product on all sides, including the space
above the play product.
Owner's Manual
Basic Setup Dimensions & Assembly Notes
23.19 ft
[7.1
m]
19.42 ft
[5.9 m]
10.02 ft
[3.1 m]
6.25 ft
[1.9 m]
6.58 ft
[2 m]
6.58 ft
[2 m]
14.18 ft
[4.3 m]
6.58 ft
[2 m]
7.60 ft
[2.3 m]
14
