Wood Components (Not to Scale)
Parts Identification
FLOOR SUPPORT BLOCK - W4L14902
1"x3 3/8"x3 3/8" (24x86x86)
J1
(x3)
COUNTER TOP SUPPORT - W4L14903
1"x2 3/8"x9 1/4" (24x60x234)
J3
(x2)
FLOOR BOARD - W4L14904
5/8"x4 3/8"x52" (16x112x1321)
L1
(x1)
GABLE BOARD - W4L14906
5/8"x4 3/8"x25 3/8" (16x112x644)
L3
(x4)
FLOOR BOARD - W4L14905
5/8"x4 3/8"x54 3/8" (16x112x1382)
L2
(x1)
GROWTH BOARD - W4L14908
5/8"x3 3/8"x60 1/4" (16x86x1530)
M1
(x1)
DECK BRACE - W4L14898
1"x3 3/8"x13" (24x86x330)
H20
(x8)
LADDER RUNG - W4L14899
1"x3 3/8"x18 1/8" (24x86x460)
H76
(x3)
LEFT UPRIGHT - W4L14900
1"x3 3/8"x38 3/8" (24x86x976)
H79
(x1)
RIGHT UPRIGHT - W4L14901
1"x3 3/8"x38 3/8" (24x86x976)
H80
(x1)
ATTACHMENT BOARD - W4L14914
1"x3 3/8"x19 1/4" (24x86x488)
H110
(x1)
WALL RAIL - W4L14896
1"x3 3/8"x16 5/8" (24x86x423)
H9
(x2)
WALL RAIL - W4L14897
1"x3 3/8"x16 3/4" (24x86x426)
H10
(x2)
WALL RAIL - W4L14923
1"x3 3/8"x55 7/8" (24x86x1418)
H11
(x1)
