Wood Components (Not to Scale)
Parts Identification
WALL BOARD - W4L14887
5/8"x3 3/8"x26 1/2" (16x86x673)
M7
(x2)
FASCIA BOARD - W4L14912
5/8"x3 3/8"x25 5/8" (16x86x652)
M33
(x4)
TIE STRAP - W4L14915
5/8"x3 3/8"x3 3/8" (16x86x86)
N1
(x8)
PICKET - W4L14918
5/8"x1 3/8"x20 1/2" (16x34x520)
O1
(x19)
WALL BOARD - W4L14911
5/8"x3 3/8"x26 1/2" (16x86x673)
M10
(x1)
REAR SUPPORT - W4L14913
5/8"x3 3/8"x19 1/4" (16x86x488)
M73
(x1)
SLIDE BRACE - W4L13297
5/8"x3 3/8"x14 1/4" (16x86x362)
M77
(x1)
SLIDE BRACE - W4L13298
5/8"x3 3/8"x14 1/4" (16x86x362)
M78
(x1)
WINDOW SHELF - W4L14917
5/8"x2 3/8"x19 1/8" (16x60x485)
N2
(x2)
RAIL BOARD - W4L14920
1"x1"x26 3/4" (24x24x679)
S1
(x2)
WINDOW TRIM - W4L14921
1"x1"x21 1/2" (24x24x545)
S2
(x2)
WINDOW TRIM - W4L14922
1"x1"x23 3/8" (24x24x594)
S3
(x2)
COUNTER TOP - W4L14907
1"x4 3/8"x36 3/4" (24x112x934)
Q1
(x2)
FLOOR BOARD - W4L14909
5/8"x3 3/8"x56 3/4" (16x86x1442)
M4
(x13)
FLOOR BOARD - W4L14886
5/8"x3 3/8"x56 3/4" (16x86x1442)
M6
(x1)
