LADDER ASSEMBLY
STEP 2
SCREW PFH BLK
8x2
(x6)
H100391
RIGHT UPRIGHT - W4L14901
1"x3 3/8"x38 3/8" (24x86x976)
H80
(x1)
391
(x6)
SCREW - 2"
H80
(x1)
28
