LADDER ASSEMBLY
STEP 4
SCREW PFH BLK
8x2
(x4)
H100391
ATTACHMENT BOARD - W4L14914
1"x3 3/8"x19 1/4" (24x86x488)
H110
(x1)
FLUSH
391
(x4)
SCREW - 2"
H110
(x1)
30
