Backyard Discovery Echo Heights - Page 45

DECK ASSEMBLY
STEP 15
PICKET - W4L14918
5/8"x1 3/8"x20 1/2" (16x34x520)
O1
(x6)
SCREW PFH BLK
8x1 1/8
(x12)
H100380
1 7/8 in
[49 m
m]
" TYP
2 1/4 in
[56 mm]
2 1/4 in
[56 mm]
380 (x12)
SCREW - 1 1/8"
O1 (x6)
45
