PLAYHOUSE
ASSEMBLY
STEP 3
SCREW PFH BLK
8x1
(x12)
H100385
WP5
(x1)
REAR CENTER PANEL - W2A03163
1 1/4"x18 7/8"x20 7/8" (32x478x536)
385
(x12)
SCREW - 1"
LEFT
B
ACK
FRONT
RIGHT
WP5
(x1)
50
