Backyard Discovery Echo Heights - Page 52

PLAYHOUSE
ASSEMBLY
STEP 5
TIE STRAP - W4L14915
5/8"x3 3/8"x3 3/8" (16x86x86)
N1
(x8)
INSTALL WITH THE EDGE
SURFACE OF 'N1' FLUSH
WITH THE END OF WALL
BOARD, AS SHOWN.
387 (x32)
SCREW - 1 1/4"
N1 (x8)
SCREW PFH BLK
8x1-1/4
(x32)
H100387
DRILL 1/8" - 3mm PILOT HOLE,
THIS HOLE ONLY.
THRU SIDING ONLY.
52
