PLAYHOUSE
ASSEMBLY
STEP 10
WINDOW SHELF - W4L14917
5/8"x2 3/8"x19 1/8" (16x60x485)
N2
(x1)
FLUSH SURFACES
N2
(x1)
387
(x2)
SCREW - 1 1/4"
SCREW PFH BLK
8x1-1/4
(x2)
H100387
57
