PLAYHOUSE
ASSEMBLY
STEP 23
DP1
(x1)
DOOR PANEL - W2A03168
1 1/8"x19 1/8"x11 3/8" (27x486x288)
KNOB - BLK
(x1)
A6P00067
HINGE (DOOR,
SPRING
LOADED)
(x1)
A4M00624
HINGE (DOOR,
NON-SPRING
LOADED)
(x1)
A4M00994
DOOR STOP
(x1)
A4M00933
067 (x1)
KNOB - BLK
933 (x1)
DOOR STOP
624 (x1)
HINGE (DOOR, SPRING LOADED)
994 (x1)
HINGE (DOOR, NON-SPRING LOADED)
395 (x2)
SCREW - 3/4"
382 (x1)
SCREW - 1 3/4"
(KNOB FASTENER)
806 (x6)
SCREW - 1 1/8"
804 (x6)
T-NUT - 8/32"
DP1 (x1)
SCREW POH BLK
8/32x1 1/8
(x6)
H100806
T-NUT
8/32
(x6)
H100804
SCREW PFH BLK
8x3/4
(x2)
H100395
SCREW PFH BLK
8x1 3/4
(x1)
H100382
