PAGE 36
STEP 17
Begin by inserting four (4) 5/16” Spike T-Nuts into G8
Swing Beam Mount (per diagram). Then attach to B4
Clubhouse Legs on right side of structure with 5/16”x 4”
Hex Bolts, 5/16” Lock Washers, Washers, and
5/16” Spike T-Nuts.
Fender
B4
G8
B4
G8
B4
B4
G8
ITEMS NEEDED
(1) G8 Swing Beam Mount
HARDWARE NEEDED
(8) 5/16” Spike Tee Nut
(4) 5/16” x 4” Hex Bolt
(4) Fender Washer
(4) 5/16” Lock Washer
