Backyard Play Systems 5027 - Assembly Procedures; Fort Assembly Steps

16
FORT
BASE
Align braces with pre-drilled holes.
FLIP ASSEMBLY OVER TO INSTALL BOTTOM BRACE.
Flush
Flush
3-3/4" Hex Bolt
Lock Washer
Flat Washer
x2
x1
2507-CC
1 x 5-1/2 x 45-1/8"
90°
Ensure all bracing is square before
installing wood screws.
FORT
CORNER POSTS
Align braces with pre-drilled holes.
BOTTOM
Flush
Flush
Flush
T-Nut
Flush
x1
x1
2503-CC
2543-CC
3 x 3 x 95"
3 x 3 x 95"
x1
1 x 3-1/2 x 45-1/8"
2501-CC
x4
x6
3-3/4" Hex Bolt
Lock Washer
Flat Washer
90°
47"
4"
4"
x1
1 x 3-1/2 x 45-1/8"
2501-CC
Note 2 hole location.
2543-CC
