Backyard Play Systems 5027 - Page 45

41
FORT
ROCK WALL-SIDE BALUSTERS
SWING-SIDE BALUSTERS
FORT
1-1/4" Wood Screws
3/4" above deck
boards
above deck
boards
3/4"
x40
1-1/4" Wood Screws
x24
x1
2859-CC
5/8 x 4-3/4 x 29-3/4"
x1
2859-CC
5/8 x 4-3/4 x 29-3/4"
2539-CC
3x3" 3x3"
Install end-balusters rst:
Flush tightly against fort
3x3" corner posts, 3/4" above
deck boards.
x8
2523-CC
5/8 x 3-1/4 x 29-3/4"
x5
2523-CC
5/8 x 3-1/4 x 29-3/4"
2523-CC
Install end-baluster rst:
Flush tightly against fort
3x3" corner posts, 3/4"
above deck boards.
BEGIN
HERE
BEGIN
HERE
BEGIN
HERE
3/4"
Flush
(ALL)
Flush
(ALL)
3x3"
VIEW
