SIDE RAILS
INSTALL
DECK SUPPORT & BAR TOP
INSTALL
LEFT
SIDE
RIGHT
SIDE
Approx.
28"
TILT FRAME UP
TO INSTALL TERRACE
Attach Terrace to
playset tower frame.
3" Wood Screws
x15
Flush
Flush
59-1/4" 59-1/4"
LEVEL
LEVEL
LEVEL
LEVEL
Flush
Flush
Flush
Ensure side rails are level
before installing wood
screws.
2-1/2" Wood Screws
x4
2" Wood Screws
x6
Flush to top
of 2877-CC
Screws into baluster top rails.
x1
3/4 x 5-1/2 x 33"
2872-CC
x1
3/4 x 2-1/2 x 45-1/8"
2516-CC
Top View
15-3/4"
15-3/4"
