Backyard Play Systems 5027 - Page 54

50
DECK PLANKS
INSTALL
DECK PLANKS
INSTALL
2-1/2" Wood Screws
x8
1-1/4" Wood Screws
x4
Middle Screws: 1-1/4" (4)
x2
3/4 x 5-1/2 x 30-1/2"
2874-CC
Ensure deck planks are ush
with side rails before installing
wood screws.
Top View
Flush with outer rails
End Screws: 2-1/2" (4)
End Screws: 2-1/2" (4)
2-1/2" Wood Screws
x24
1-1/4" Wood Screws
x12
End Screws: 2-1/2" (24)
End Screws: 2-1/2"
Middle Screws: 1-1/4 " (12)
x6
3/4 x 5-1/2 x 30-1/2"
2875-CC
Ensure equal spacing
of deck planks before
installing wood screws.
Top View
Equally spaced
Flush
Note hole
location.
