STEP 3
TOP
T-NUT 5/16 (16)
RIGHT
L
EFT
T-NUT 5/16
(4 PLCS)
T-NUT 5/16
(4 PLCS)
T-NUT 5/16
(4 PLCS)
T-NUT 5/16
(4 PLCS)
INSIDE SURFACE
B3
B2
B2 - UPRIGHT POST - W4L07119
3
"x3"x89 1/2" (76x76x2274)
(1)
B3 - UPRIGHT POST - W4L07120
3"x3"x89 1/2" (76x76x2274)
(1)
NOTE HOLE
LOCATION.
NOTE HOLE
LOCATION.
30
